E Series Service Manual
9650-1450-01 Rev. D 5-15
9. From the opposite corner, remove colored stranded cable. 10.Gently separate the system board from its cradle.
Note: Board has tabs holding it into slots in the metal frame
at the bottom.
11. Remove the 3 flat cables by pulling co
nnector straight out, and
remove system board.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ZOLL E Series and is the answer not in the manual?

ZOLL E Series Specifications

General IconGeneral
Display TypeColor LCD
ECG MonitoringYes
PacingYes
Pacing Rate30-180 ppm
SpO2Optional
NIBPOptional
EtCO2Optional
PrinterIntegrated
Data ManagementYes
CPR FeedbackYes
IP RatingIP55
Pacing Output0 - 140 mA
Battery TypeRechargeable lithium ion
Battery Life4 hours
Energy Selection1-360 Joules
Display Size6.5 inches
