E Series Service Manual
1-22 9650-1450-01 Rev. D
12.0 Synchronized Cardioversion Test
Tools Needed: QED 6 Defibrillator Analyzer.
Test Setup:
1. Connect the universal cable via the adapter (D.N.I #3
010-0378) to the defibrillator analyzer.
2. Set ECG on analyzer to 60 -120 BPM.
Do this... Verify that... Pass/Fail
12.1
12.2
Note: Syn
c markers display on the monitor. The sync marker appears as a
down arrow over the ECG R-wave peaks on strip chart and display.
o o
12.3
o o
Press LEAD button to select PADS and Size
x1.
Press the SYNC so
ftkey on the defibrillator.
Enter synchronized cardioversion timing test
mode on the defibrillator analyzer.
Sync markers appear on display.
Select 200J, and then press the CHARGE
b
utton. When the SHOCK button lights, press
and hold the SHOCK button.
On the analyzer display, the R-wave to shock delay is less than 
60 milliseconds.
Record your results on the Maintenance Tests Checklist.
