Display

Recorder

PCMCIA Card

Battery Packs

Screen Type High resolution, color liquid crystal display (LCD)

Screen Size 5.63 inches (14.3 cm) diagonally

Sweep Speed 25 mm/s

Viewing Time 4 seconds

Messages ERASING REPORT, INSERT CARD, CARD FULL, REPLACE BATTERY, LOW BATTERY,

PERFORM CPR, ECG TOO LARGE, NOISY ECG, RETRY ANALYSIS, CHECK PATIENT,

ANALYSIS HALTED, PRESS ANALYZE, NO SHOCK ADV., CHECK PULSE,

SHOCK ADVISED, PRESS CHARGE, SELECT PADS, SELECT ECG LEADS,

SELECT DEFIB MODE, VF ALARMS OFF, DISABLE SYNC, ANALYSIS RESTARTED,

CHECK PADS, POOR PAD CONTACT, DEFIB PAD SHORT, PADDLE FAULT,

ECG LEAD OFF, USE PADDLE DISCHG, OPEN AIR DISCHARGE, CANNOT CHARGE,

RELEASE SHOCK, PRESS SHOCK, TEST OK, TEST FAILED, PACER DISABLED,

DEFIB DISABLED, SET PACE MA, SET PACE RATE, CHECK RECORDER,

ANALYZING ECG, FULLY RELEASE.

Paper 80 mm thermal (grid width)

90 mm (paper width)

Speed 25 mm/s or 50 mm/s (apparent), configurable for 12 lead output

Delay 6 seconds

Annotations Time, date, defib energy, heat rate, pacer output (Pacer version only), QRS sync marker,

ECG SIZE, lead, alarm, DEFIB TEST OK/FAIL, ANALYZE ECG, PADS OFF, ANALYSIS

HALTED, NOISY ECG, SHOCK ADVISED, NO SHOCK ADVISED, ECG TOO LARGE, and

diagnostic bandwidth.

Printing Method High resolution, thermal array print head

Print out Modes Manual or automatic; user-configurable

On/Off Control Front panel and paddle

Automatic Function 15 second recording initiated by alarm activation or defibrillator discharge

Capacity Standard Series II Flash card - 8, 16, or 32 Mb

Audio Recording Digital compressed audio data

Type Rechargeable, sealed lead acid Lithium ion

Weight 1 kg (2.2 lbs) 0.68 kg (1.5 lbs)

Voltage 2 Volts per cell; 5 cells wired in series 4.2 Volts per cell; 3 cells wired in series

Recharge Time

(to 90% capacity)

4 hours or less with integral charger 7 hours or less with integral charger

ZOLL E Series Service Manual
