E Series Service Manual
9650-1450-01 Rev. D 2-5
ZOLL E Series Error Messages
The following is a list of ZOLL E Series error messages that may appear on your display. The “User Advisory” column informs you about an action in
progress or provides feedback on a user correctable situation that typically does not require further technical support. The “Technical Action” column
describes what you as a technician can do to correct the situation. Note that these messages will sometimes overlap part of the waveform display.
First, attempt to clear the message by turning the Selector Switch to OFF for ten seconds, then back to the desired operating mode. If the fault persists, call
ZOLL Technical Service.
Error Message Explanation User
Advisory
Technical Action
200J MAX BIPHASIC User attempted to set defibrillation energy >200J on
Biphasic Unit. No higher energy is available.
ANALYSIS HALTED
ECG analysis halted due to user interaction such as:
Lead/size change
Analyze button was pressed again
Impedance fault
Charging error detected in auto defib mode
AUDIO FAULT 136 Audio DSP hardware error. Replace audio board.
Replace system board.Turn unit off and back on
again.
AUDIO NOT RECORDING Audio is not recording.
Install PCMCIA card. Replace system board.
AUDIO QUEUE FULL Indicates that the audio output queue is full. Additional
voice prompts can't be queued at this time.
None.
BATT HIGH CURRENT Battery is charged and battery current is >.1 A or:
Battery is not charged and battery current is > 1.6 A.
Unplug from A/C. Remove the battery for 20
seconds. Reconnect all above. If the problem
persists, replace battery and or charger.
BATT HIGH VOLTAGE Battery voltage > 15.5 v.
Replace battery and or charger
BATT LOW CURRENT Battery is not charged and battery current is <.35 A.
Replace battery and or charger.
BATT LOW VOLTAGE Battery voltage < 9.5 v. Replace battery and or charger.
BATT OVERCHARGE Charger on for > 4 hours.
Replace battery and or charger.
