ZOLL E Series Service Manual

E Series Service Manual
1-18 9650-1450-01 Rev. D
10.0 Heart Rate Alarm Test
Tools Needed: QED 6 Defibrillator Analyzer
Do this... Verify that... Pass Fail/NA
10.1 Turn the selector switch to MONITOR mode.
(For AED units, turn the selector switch to ON
and select Manual mode.)
Connect the ECG leads to the QED 6
Defibrillator Analyzer
. Set the QED 6 Analyzer
to 120 BPM and the defibrillator to lead II.
The monitor screen displays the Lead II message and the waveform for
NSR ECG at 120 BPM +/- 2.
o o o
10.2 Press ALARMS buttons. The monitor displays the alarm menu.
o o o
10.3 Press SELECT PARAM softkey until ECG HR
displays.
The cursor scrolls through parameters.
o o o
10.4 Press INC> for state. The cursor scrolls through ENABLE, AUTO and DISABLE.
o o o
10.5 Press DEC>for state. The cursor scrolls through ENABLE, DISABLE, AND AUTO.
o o o
10.6 Press INC> until ENABLE displays. ENABLE appears.
o o o
10.7 Then press the NEXT FIELD softkey to select
the heart rate limit.
The cursor scrolls to Low field.
o o o
10.8 Press Return, then press the ALARM
SUSPEND button.
No alarm sounds.
o o o
10.9 Remove a lead wire from the QED 6 analyzer. The alarm symbol flashes and the heart symbol stops flashing. The ECG LEAD
OFF alarm tone sounds. Recorder prints a stripchart showing a low heart rate,
if enabled.
o o o
10.10 Re-attach ECG Lead wire to the QED 6
Analyzer and hold the ALARM SUSPEND
button on unit for 4 seconds.
The unit displays the alarm symbol with an “X” through it.
The heart symbol flashes with each QRS wave.
o o o
10.11 Press the ALARM SUSPEND button to enable
the alarms.
The alarm symbol does not have an “X” through it.
o o o
10.12 Set QED 6 Analyzer to 160 BPM or higher. The Heart Rate Value is highlighted, the alarm tone sounds, and the alarm and
the heart symbol both flash.
o o o
10.13 Press the ALARM SUSPEND button on the E
Series unit.
The alarm is suspended for 90 seconds. The unit displays the alarm symbol
with an “X” through it, and the heart symbol flashes with each QRS wave.
o o o

ZOLL E Series Specifications

General

Display Type	Color LCD
ECG Monitoring	Yes
Pacing	Yes
Pacing Rate	30-180 ppm
SpO2	Optional
NIBP	Optional
EtCO2	Optional
Printer	Integrated
Data Management	Yes
CPR Feedback	Yes
IP Rating	IP55
Pacing Output	0 - 140 mA
Battery Type	Rechargeable lithium ion
Battery Life	4 hours
Energy Selection	1-360 Joules
Display Size	6.5 inches
