E Series Service Manual
9650-1450-01 Rev. D 1-41
24.0 Bluetooth Test
Tools Needed: USB Bluetooth dongle with driver CD. Bluetooth application software BlueSoleil.
Test Setup:
Verify that the E Series unit is configured as follows: Bluetooth --
INSTALLED; Bluetooth Baud Rate -- 115200.
Do this... Verify that... Pass/Fail
24.1
o o
24.2
24.3
o o
24.4
Note: Note:
If setting up Hyperterminal for the
first time set COM PORT programmed
for Bluetooth adapter, 115200bps, 8, N,
1, N
24.5
o o
Power up the E Series unit while pressing in
and holding the left-most soft key.
The E Series unit displays the System Utilities Menu.
Insert a PCMCIA card containing data into the
ca
rd reader
Press the UPLOAD CARD
softkey, then press
the softkey UPLOAD CARD.
Press the softkey SEND, then press the softkey
Bluetooth.
Verify that the Bluetooth LED is on and green.
Double click on the HyperTerminal shortcut
(BT
115200) from the desktop.
In the IVT Corporation BlueSoleil window under
“View”, select refresh devices and in the IVT
Corporation BlueSoleil – Main Window. Find the
unit under test Serial Number and double click
on it.
Find the Serial Port Icon and click on it, (it will
b
e highlighted
At the bottom of the window it states Connected,
The file transfer window pops up and the file upload progress bar goes to
100%.
The unit displays the file upload message, Card Uploaded.
Record your results on the Mai
ntenance Tests Checklist.
