E Series Service Manual
9650-1450-01 Rev. D 1-35
21.0NIBP Volume Leak Test with Fluke Biomedical NIBP Analyzer
The volume leak test verifies the integrity of the pneumatic system on the NIBP module. This test is optional at 6 months, but should be performed
annually or every 10,000 readings, whichever comes first.
Tools Needed: Fluke NIBP simulator (the values and procedure that we provide are specific to the BP Pump 2).
Test Setup:
1. Connect the Analyzer’s simulator hose to the NIBP connector on the E Series unit.
2. Configure the NIBP Analyzer for the volume leak test. For example, on the Fluke Biomedical BP Pump:
• Press the Cuff softkey for volume cuff test.
• Verify the cuff is set to External
3. Make sure the ECG cable is not connected to the E Series unit.
4. If the SpO2 option is installed, make sure that the Masimo cable is NOT connected to the E Series unit.
NIBP Volume Leak Test with Fluke Biomedical Cufflink NIBP Analyzer
Do this... Verify that... Pass/Fail
21.1 Turn the Selector Switch to OFF.
After 10 seconds, press and hold the fourth
softkey from the left and turn the Selector
Switch to MONITOR (For AED units, turn the
selector switch to ON).
The E Series unit powers on in the NIBP Service Mode.
o o
21.2 Press the Leak Test softkey. The E Series unit displays the NIBP Leak Test Screen.
o o
21.3 On the NIBP simulator, set the pressure
parameter to 200 mmHg.
The NIBP simulator displays a pressure reading of 200 mmHg.
o o
21.4 On the E Series unit, press the Close Valves
softkey.
The Valves status changes from OPEN to CLOSED.
o o
To Next Page
