ZOLL E Series Service Manual

E Series Service Manual
1-34 9650-1450-01 Rev. D
20.9 Attach a regulated flowing gas mixture of 5%
CO
2
/balance Nitrogen (N
2
) to the airway
adapter.
The gas flow rate should already be preset to 2 to 5 liters per minute.
20.10 Set the Gas Balance settings of the
CAPNOSTAT 5 CO
2
Sensor to that of the
calibration gas mixture (N
2
, N
2
O, or He).
The default gas balance is N
2
.
20.11 Allow a few seconds for the gas mixture to
stabilize and observe the CO
2
Percent value.
The expected value is 4.8 to 5.2.
o o o
20.12 Press the Return softkey to return to the main
EtCO
2
Calibration screen.
20.13 Turn the device off when calibration is
complete.
Record your results on the Maintenance Test Checklist.
Do this... Observe this... Pass/Fail/NA

ZOLL E Series Specifications

General

Display Type	Color LCD
ECG Monitoring	Yes
Pacing	Yes
Pacing Rate	30-180 ppm
SpO2	Optional
NIBP	Optional
EtCO2	Optional
Printer	Integrated
Data Management	Yes
CPR Feedback	Yes
IP Rating	IP55
Pacing Output	0 - 140 mA
Battery Type	Rechargeable lithium ion
Battery Life	4 hours
Energy Selection	1-360 Joules
Display Size	6.5 inches
