E Series Service Manual
1-26 9650-1450-01 Rev. D
15.0 Advisory Message Test
Tools Needed: QED 6 Defibrillator Analyzer.
Test Setup:
1. Connect the universal cable via t
he adapter (D.N.I #3010-0378).
2. Attach the E Series to the QED 6 Defibrillator Analyzer.
Do this... Verify that... Pass/Fail
15.1
15.2
o o
15.3
o o
15.4
o o
Turn the selector switch to DEFIB mode.
(For AED units, turn the selector switch to ON.)
Select VF (ventricular fi
brillation) on the
simulator, then press the ANALYZE button.
The unit displays the following messages:
ANALYZING ECG.
STAND CLEAR.*
SHOCK ADVISED.*
PRESS SHOCK.*+
*AED’s audio prompts are standard. Advisory audio prompts are user
configurable.
+If configured for auto charge.
Press the SHOCK b
utton. The unit discharges.
Select the NSR (normal
sinus rhythm) on the
simulator, then press the ANALYZE button.
The unit displays the following messages:
ANALYZING ECG.
STAND CLEAR.*
NO SHOCK ADVISED.*
*AED’s audio prompts are standard.
Record your results on the Maintenance Tests Checklist.
