9650-1210-01 Rev. R A-1

APPENDIX A

SPECIFICATIONS

General

Size 5.75 in. high x 13.1 in. wide x 10.5 in. deep

14.6 cm high x 33.3 cm wide x 26.7 cm deep

Weight Approximately 13.2 lbs (5.99 kg)

Power 5 cells, 2 V/cell; wired in series (sealed lead acid battery pack)

3 cells, 4.2 V/cell; wired in series (lithium-ion battery pack)

AC Power 100-120V ~ 50/60 Hz, 220-240V ~ 50 Hz, 220 VA

DC Input (Optional) 10-29 V. 130 W

Device Classification Class I and internally powered per IEC 60601-1.

Class II and internally powered per IEC 60601-1 (DC input ONLY).

Design Standards Meets or exceeds UL 60601-1, AAMI DF-80, IEC 60601-2-4, EN 60601-2-25, and

EN 60601-2-27.

Patient Safety All patient connections are electrically isolated.

Environmental

Temperature: Operating: 0C to 55C (32F to 131F)

Storage Temperature: -20 to 60C (-4F to 140F)

Note: The E Series device may not perform to specifications when stored at the upper or

lower extreme limits of storage temperature and immediately put into use.

Humidity: 5 to 95% relative humidity, non-condensing

Vibration: Mil-Std-810F, Minimum Integrity Test

Shock: IEC 68-2-27, 100 g 6 mS half sine

Operating Pressure: 594 to 1060 mBar

Material Ingress: IP34 per EN 60601-1

Electromagnetic

Compatibility (EMC):

CISPR 11 Class B - Radiated and Conducted Emissions

CISPR 11 Class A - Radiated and Conducted Emissions (DC input only)

Electromagnetic

Immunity

AAMI DF-80, IEC 61000-4-3 to 10 V/m

Electrostatic Discharge AAMI DF-80, IEC 61000-4-2

Conducted

Susceptibility

IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6

ZOLL E Series Service Manual
