E Series Service Manual
9650-1450-01 Rev. D 1-17
9.0 Notch Filter Test
Tools Needed: QED 6 Defibrillator Analyzer.
Test Setup:
1. Connect the ECG cable to the QED 6 Defibrillator Analyzer.
2. Connect the ECG cable to the unit.
Do this... Verify that... Pass/Fail/NA
9.1
9.2
9.3
o o o
Turn the selector switch to MONITOR mode.
(For AED units, turn the selector switch to ON
and select Manual mode.)
Select lead I, size 3x.
Se
lect 60Hz (or 50 Hz for a 50Hz unit) on 
the QED 6 Defibrillator Analyzer.
Press RECORDER button.
Verify that the waveform amplitude on the strip chart is less than 1.5 mm.
Record your results on the Mai
ntenance Tests Checklist.
