ZOLL E Series Service Manual

E Series Service Manual
1-36 9650-1450-01 Rev. D
5
If
you are using the Fluke® Biomedica l Cuftlin k Simulator,the volume leak reading should be <10.
6
If you are using the Fluke® BiomedicalCuftlink Simulator,the volume leak reading for a failure should be >10.
21.5 Press the START TEST softkey within 30
seconds after closing the valve.
Note: This test takes approximately 3 minutes.
After approximately 1 minute, a number appears in the upper middle area of
the NIBP simulator display.
If the simulator:
• Displays a Volume Leak reading <5,
5
then the E Series unit has passed the
test.
• Displays a Volume Leak reading >5,
6
then the E Series unit has failed the
test.
• Displays no Volume Leak reading, but maintains a stable pressure reading
at or above 200 mmHg, then the E Series unit has passed the test; there is
no volume leak.
In addition, the E Series unit displays the simulator’s pressure reading in the
“Cuff Pressure” field.
After approximately 3 minutes, the valves open on the E Series unit.
o o
21.6 On the NIBP Analyzer, press the STOP TEST
softkey.
The NIBP simulator terminates the Volume Leak Test.
o o
21.7 On the E Series unit, press the EXIT softkey
twice.
The E Series unit returns to the main NIBP Service Mode screen, then to
normal Monitor mode operation.
o o
Record your results on the Maintenance Tests Checklist.
Do this... Verify that... Pass/Fail

ZOLL E Series Specifications

General

Display Type	Color LCD
ECG Monitoring	Yes
Pacing	Yes
Pacing Rate	30-180 ppm
SpO2	Optional
NIBP	Optional
EtCO2	Optional
Printer	Integrated
Data Management	Yes
CPR Feedback	Yes
IP Rating	IP55
Pacing Output	0 - 140 mA
Battery Type	Rechargeable lithium ion
Battery Life	4 hours
Energy Selection	1-360 Joules
Display Size	6.5 inches
