E Series Service Manual
9650-1450-01 Rev. D 1-21
Note: The universal cable should not be connected to any equipment at the beginning of this test.
Do this... Verify that... Pass/Fail
11.1
o o
11.2
o o
11.3
o o
11.4
o o
11.5
o o
11.6
o o
11.7
o o
Turn the selector switch to DEFIB mode.
(For AED units, turn the selector switch to ON
and select Manual mode.)
Set leads to PADS.
The unit displays the CHECK PADS/POOR PAD CONTACT message.
Connect the universal cable to the MFC test
po
rt.
DEFIB PAD SHORT message displays.
Select energy level of 100J and press the
C
HARGE button.
The charge time is greater than 2 seconds and less than 10 seconds and the
unit displays the message, SELECT 30J FOR TEST.
Press the SHOCK b
utton. The unit does not discharge. The unit displays the message, DEFIB PAD
SHORT.
Set energy level to 30J. The unit discharges internally.
Press the CHARGE button. The unit charges to 30J and displays message, DEFIB 30J READY. The
charge ready tone sounds.
Press and hold SHOCK button.
The unit discharges and displays the number of joules delivered and theï€
TEST OK message. For example, the message at the top of the printed strip
chart would read as follows:
30 JOULES TEST OK. TEST_CUR=10-14A DEFIB_IMPED=0.
The impedance value may range from 0 to 5 ohms.
Record your results on the Mai
ntenance Tests Checklist.
