E Series Service Manual
9650-1450-01 Rev. D 5-21
5. Loosen the 3 screws holding plastic frame in place. Lift the
entire frame out of the chassis.
6. Remove bridge board isolator (clear).
7. Disconnect flex cable from bridge board by lifting the tabs and
pulling straight up.
8. Remove 3 screws.
