ZOLL E Series Service Manual

E Series Service Manual
1-8 9650-1450-01 Rev. D
2.9 Press the INC softkey. The bar graph appears on the display, indicating an increase in volume.
Note: This action does not increase the volume of the unit’s audio prompts.
o o
2.10 Press the DEC softkey. The bar graph appears on the display, indicating a decrease in volume.
Verify that pressing the DEC softkey until only the last bar appears silences the
unit’s audio prompts, otherwise the volume of the audio prompts does not
decrease.
o o
2.11 Press the CONTRAST button. The monitor screen displays the Contrast Menu.
o o
2.12 Press the INC softkey. The screen contrast and bar graph increases on the display.
o o o
2.13 Press the DEC softkey. The screen contrast and bar graph decreases on the display.
o o
2.14 Press the SUMMARY button. The monitor screen displays the Summary menu, showing the summary report
options.
o o o
2.15 Press the CODEMARKER button. The monitor screen displays the Code marker menu.
o o o
2.16 Connect to AC or DC current and install the
battery. Turn the unit off.
The CHARGER ON indicator lights (either the Green or Amber indicator lights).
o o o
2.17 Remove the battery. The charger light alternately flashes green and amber.
o o
2.18 Replace the battery and the turn unit on. The amber charger light illuminates.
o o
2.19 Press the ANALYZE button. The SELECT DEFIB MODE message appears on the monitor (for manual
devices).
o o o
2.20 Move the selector switch to DEFIB. Select 2J.
Press the CHARGE button.
The display shows that the unit is charging. The SHOCK button lights when the
unit is charged, and the Ready tone for DEFIB sounds.
o o o
2.21 Press and hold the ENERGY SELECT down
arrow.
The unit discharges internally and selected energy decrements to 1J.
o o o
2.22 Press and release the ENERGY SELECT up
arrow 19 times.
The following selections appear: 1-10, 15, 20, 30, 50, 70, 85, 100, 120, 150,
200J.
o o o
2.23 Press the CHARGE button. The display shows the unit charged up to 200J and the SHOCK button lights.
o o o
Do this... Verify that... Pass/Fail/NA

ZOLL E Series Specifications

General

Display Type	Color LCD
ECG Monitoring	Yes
Pacing	Yes
Pacing Rate	30-180 ppm
SpO2	Optional
NIBP	Optional
EtCO2	Optional
Printer	Integrated
Data Management	Yes
CPR Feedback	Yes
IP Rating	IP55
Pacing Output	0 - 140 mA
Battery Type	Rechargeable lithium ion
Battery Life	4 hours
Energy Selection	1-360 Joules
Display Size	6.5 inches
