E Series Service Manual
1-24 9650-1450-01 Rev. D
13.10 Press the CHARGE button. Wait for the
SHOCK button to illuminate.
The unit displays the message, DEFIB 100J RDY.
o o o
13.11 Press the SHOCK button. The unit discharges 83J-122J into the simulator.
o o o
13.12 Press the ENERGY SELECT up arrow until the
unit displays 200J.
The unit displays the message, DEFIB 200J SEL
o o o
13.13 Press the CHARGE button. Wait for the
SHOCK button to illuminate.
The unit displays the message, DEFIB 200J RDY.
o o o
13.14 Press the SHOCK button. The unit discharges 182J-247J into the simulator.
o o o
13.15 Press the CHARGE button and start timing with
a stopwatch. Stop timing when the SHOCK
button lights.
The charge time is between 3-6 seconds.
o o o
13.16 Press the SHOCK button. On the strip chart, the Patient Current is between 20-24 Amps, and the Defib
Impedance is between 46-54 Ohms.
o o o
13.17 Turn unit to Defib (for AED units, turn to on and
select Manual Mode.
o o o
13.18 Set energy level to 200 Joules. Press
CHARGE. When the SHOCK button lights,
press the Energy SELECT DOWN ARROW.
The unit does not display any fault messages, and the QED 6 Defibrillator
Analyzer shows that no discharges have been delivered.
o o o
13.19 Set energy level to 200 Joules. Have the stop
watch ready. Press CHARGE. When the
SHOCK button lights, start the stop watch.
The unit holds the energy for 60 seconds (15 seconds for AED units), then the
unit discharges internally. The unit does not display fault messages.
o o o
13.20 (AED units only.) Disconnect the cable from the
analyzer.
The unit issues the CHECK PADS audio prompt.
o o o
Record your results on the Maintenance Tests Checklist.
Do this... Verify that... Pass/Fail/NA
