107
▶ Continue to one of the following procedures.
Setting the routing ……………………………………………………………… P.107
Using mono headphone output ………………………………………… P.107
Monitoring mid-side stereo signals…………………………………… P.108
■ Setting the routing
6. Use and to select the tracks/outputs for head-
phone routing and press
.
Mid-side stereo
monitoring
Mono mix
Clear all settings
Set to post-fader
Set to pre-fader
Off
Tracks routed to left
headphone channel
Tracks routed to right
headphone channel
Press to cycle through
settings
• Change tracks 1–6 to
post-fader (cancel others)
• Change L/R to post-fader
(cancel others)
• Change Line to post-fader
(cancel others)
• Change U1–U4 to post-fader
(cancel others)
Set all tracks 1–6 to
pre-fader (cancel MS)
HINT
Press ENTER to cycle through the options: prefader → postfader → off.
NOTE
•
• L/R and line outputs cannot be set to prefader.
•
• When AIF with Rec is set to On, USB track 1–4 can be assigned.
•
• The 1–6, L/R, line outputs and USB track 1–4 cannot be selected at the
same time. Selecting one type will deselect any other.
7. Press .
■ Using mono headphone output
6. Use and to select
Mono
, and press
.
7. Press .
To Next Page
