Zte ZXR10 ZSR V2 - Example: Configuring a Router to Join a Static MLD Group and a; Dynamic MLD Group; Figure 12-2 Example for Configuring a Router to Join a Static MLD Group and a Dynamic MLD Group

ZXR10ZSRV2CongurationGuide(IPv6)
Internetaddressisfe80::2
MLDisenabledoninterface
CurrentMLDversionis2
MLDqueryintervalis125seconds
MLDlastmemberqueryintervalis1seconds
MLDquerymaxresponsetimeis10seconds
MLDqueriertimeoutperiodis255seconds
MLDrobustnessvariableis2
MLDquerierisfe80::2,expiretimer:00:03:33
InboundMLDaccessgroupisnotset
MLDimmediateleavecontrolisnotset
12.3.2Example:ConfiguringaRoutertoJoinaStaticMLDGroup
andaDynamicMLDGroup
CongurationDescription
AsshowninFigure12-2,PIM-SMisenabledonR1.TheMLDversionisv2(default).It
isrequiredtocongureR1tojoinastaticgroupffee::1,andcongureittojoinadynamic
groupffee::2throughaPC.
Figure12-2ExampleforConguringaRoutertoJoinaStaticMLDGroupanda
DynamicMLDGroup
CongurationFlow
1.Congureaddressesontheinterfacesoftheroutersininterfacecongurationmode.
2.Enablethemulticastfunctionbyconguringtheipv6multicast-routingcommand.
3.EnterPIMroutemodeandthenentertheinterfaces.
4.EnablePIM-SMininterfacecongurationmode.
5.Inmulticastmode,enterMLDroutemodeandthenentertheinterfacestobe
congured.
6.Congurethestaticgroupongei-1/1ofR1.
7.SendMLDgroupjoinmessagestoR1onthePC.
CongurationCommands
ThecongurationofR1isasfollows:
R1(config)#interfacegei-1/1
R1(config-if-gei-1/1)#ipv6enable
R1(config-if-gei-1/1)#ipv6address100::1/64
R1(config-if-gei-1/1)#noshutdown
12-8
SJ-20140504150128-018|2014-05-10(R1.0)ZTEProprietaryandCondential
