ZXR10ZSRV2CongurationGuide(IPv6)
18.2Conguring6PE
Thisproceduredescribeshowtocongure6PE.
Steps
1.Congure6PE.
StepCommandDescription
1ZXR10(config)#routerbgp<as-number>EnterstheBGPconguration
mode.
2ZXR10(config-bgp)#address-familyipv6EnterstheIPv6unicastaddress
familycongurationmode.
3ZXR10(config-bgp-af-ipv6)#neighbor
{<ipv4-address>|<peer-group-name>}activate
EnablesIPv6forIPv4
neighbors.
4ZXR10(config-bgp-af-ipv6)#neighbor
{<ipv4-address>|<peer-group-name>}send-labe
Enableslabeladvertisementfor
neighbors.
2.Verifythecongurations.
CommandDescription
ZXR10(config)#showbgpipv6unicastneighbor<ipv4-address>Displaysthedetailedinformation
abouttheIPv6neighbor.
ZXR10(config)#showbgpipv6unicastlabelsDisplaysthelabelinformation
relatingtoBGPIPv6routes.
–EndofSteps–
18.36PECongurationExample
CongurationDescription
AsshowninFigure18-2,PE1andPE2areconguredwith6PE.PE1andPE2establish
LDPneighborsandOSPFneighborsviathedirectconnectioninterfacestoadvertise
theirloopback1interfaceaddresses,andestablishMP-BGPneighborsviatheloopback1
interfacestoadvertisetheirIPv6networksegmentsandredistributethedirectIPv6route.
18-2
