Chapter22IPv6QoSConguration
ZXR10(config-pmap-c)#exit
ZXR10(config-pmap)#classdscp2
ZXR10(config-pmap-c)#bandwidthpercent30
ZXR10(config-pmap-c)#exit
ZXR10(config-pmap)#classdscp3
ZXR10(config-pmap-c)#bandwidthpercent20
ZXR10(config-pmap-c)#exit
ZXR10(config-pmap)#classdscp4
ZXR10(config-pmap-c)#bandwidthpercent10
ZXR10(config-pmap-c)#exit
ZXR10(config-pmap)#exit
4.Bindthepoliciestotheinterface.
ZXR10(config)#service-policygei-1/3outputtest
CongurationVerication
Runtheshowpolicy-mapcommandtocheckthecorrectnessofpolicyconguration.
ZXR10(config)#showpolicy-map
policy-maptest
classdscp1
priority-llq
policecir400000cbs400conform-actiontransmitexceed-actiondrop
violate-actiondrop
classdscp2
bandwidthpercent30
classdscp3
bandwidthpercent20
classdscp4
bandwidthpercent10
Runtheshowservice-policycommandtocheckthecorrectnessofinterface-policybinding.
ZXR10#showservice-policy
service-policygei-1/3outputtest
22.3.2Example:ConfiguringIPv6WRED
CongurationDescription
CongureaWeightedRandomEarlyDetection(WRED)policyintheuplinkoftherouter
interface,sothatdifferentdiscardpoliciesareappliedtothepacketsofdifferentpriorities
whencongestionoccurs.Thefollowingobjectivesshouldbeattained:
22-3
