Chapter13
IPv6PIM-DMConguration
TableofContents
PIM-DMOverview....................................................................................................13-1
ConguringIPv6PIM-DM.........................................................................................13-1
IPv6PIM-DMCongurationExample.......................................................................13-2
13.1PIM-DMOverview
IntheProtocolIndependentMulticast-DenseMode(PIM-DM),itisassumedthatthereare
manymulticastreceiverswhicharedistributedonmostnetworkdevices.Basedonthe
aboveapplicationmode,themechanismofthePIM-DMprotocolisrelativelysimple.It
diffusesthemulticasttrafctoalldevicesinthenetworkperiodicallythroughthePUSH
mode,andthenestablishandmaintainanSPTforwardingtree.
lWithPIM-DM,itisassumedthateachsub-netinthenetworkhasatleastonemember
existinginamulticastgroup.Inthiscase,themulticastdataisdiffusedtoallnodesin
thenetwork.
lPIM-DMwillcutthebrancheswithnoforwardedmulticastdata,andsaveonly
thebrancheswithareceiver.The"diffuse-cutbranches"operationtakesplace
periodically,andthecutbranchesrecovertoforwardingstatusperiodically.
lWhenthecutbrancheshaveamemberthatexistsinthemulticastgroup,thisnode
sendsmessagestotheupperstreamactively.Inthiscase,thisnodechangestothe
forwardingstatus,andthemulticastdataisforwardedtothisbranch.
13.2ConguringIPv6PIM-DM
ThisproceduredescribeshowtocongureIPv6PIM-DM.
Steps
1.CongureIPv6PIM-DM.
StepCommandFunction
1ZXR10(config)#ipv6multicast-routingEnablestheIPv6multicast.
2ZXR10(config-mcast-ipv6)#routerpimEnablesthePIMprotocoloftheIPv6
multicast.
3ZXR10(config-mcast-ipv6-pim)#interface
<interface-name>
EnterstheIPv6PIMinterfaceconguration
mode.
13-1
