Zte ZXR10 ZSR V2 - Figure 19-2 Network Topology of the Ipv6 Static Route Configuration between CE and PE

ZXR10ZSRV2CongurationGuide(IPv6)
Figure19-2NetworkTopologyoftheIPv6StaticRouteCongurationBetween
CEandPE
CongurationonCE1:
CE1(config)#interfacegei-1/1
CE1(config-if-gei-1/1)#ipv6enable
CE1(config-if-gei-1/1)#ipv6address1001::20:1/96
CE1(config-if-gei-1/1)#exit
CE1(config)#interfacegei-1/2
CE1(config-if-gei-1/2)#ipv6enable
CE1(config-if-gei-1/2)#ipv6address1001::10:2/120
CE1(config-if-gei-1/2)#exit
CE1(config)#ipv6route2002::0/961001::10:1
CongurationonPE1:
PE1(config)#ipv6routevrfvpn_a1001::0/961001::10:2
PE1(config)#routerbgp100
PE1(config-bgp)#address-familyipv6vrfvpn_a
PE1(config-bgp-af-ipv6-vrf)#redistributestatic
PE1(config-bgp-af-ipv6-vrf)#exit
4.CongureRIPngbetweenaCEandaPE.
StepCommandFunction
1ZXR10(config)#ipv6routerripvrf<vrf-name>EnablesRIPngandenters
RIPngcongurationmode.
2ZXR10(config-ripng-vrf-vrf-name)#redistributebgp
[metric<metric-value>],[route-map<map-tag>]
RedistributesBGPtoRIPng.
19-4
SJ-20140504150128-018|2014-05-10(R1.0)ZTEProprietaryandCondential
