ZXR10ZSRV2CongurationGuide(IPv6)
thepacket.Ifthematchedtunnelentityisfound,theIPv4headerencapsulatedis
removed,andtheleftIPv6packetishandledaccordingtotheIPv6packetreceiving
ow.
Figure16-9showstheISATAPtunnelprinciple.
Figure16-9ISATAPTunnelPrinciple
16.2.2ConfiguringISATAPTunnels
ThisproceduredescribeshowtocongureISATAPtunnels.
Steps
1.CongureanISATAPtunnel.
StepCommandFunction
1ZXR10(config)#interfacev6_tunnel<tunnel_no>CreatesanIPv6tunnel
interface.
2ZXR10(config-if-v6_tunnel)#ipv6enableEnablesIPv6.
3ZXR10(config-if-v6_tunnel)#ipv6address<addrprefix
/prefix-len>eui-64
Conguresaneui-64address
onaninterfaceforanISATAP
tunnel.
4ZXR10(config)#ipv6-tunnel-configEntersIPv6tunnel
congurationmode.
5ZXR10(config-v6_tunnel)#interface{byname
<interface-byname>|<interface-name>}
EntersIPv6tunnelinterface
congurationmode.The
interfacealiasandinterface
namecancontainupto32
characters.
6ZXR10(config-ipv6-tunnel-if-v6_tunnel)#tunnel
modeipv6ipisatap
Setsthetunnelmodeto
isatap.
