ZXR10ZSRV2CongurationGuide(IPv6)
CongurationFlow
TocongureanISATAPtunnel,itisnecessarytoenableIPv6andbindtheIPv4address
oftherouteratthesourceendofthetunnel.Itisunnecessarytocongurethedestination
address.Thecongurationstepsaredescribedbelow:
1.CreateanISATAPtunnel.CongureanIPv6addressandenableIPv6.TheIPv6
addressontheISATAPinterfaceuseseuimode.
2.Entertunnelcongurationmodefromglobalcongurationmode,andthenenterthe
ISATAPtunnelinterfacetobecongured.
3.Congurethetunnelmodeandthesourceaddress.
4.CongurestaticroutesorBGP4+toadvertisethetunnelroute.
CongurationCommands
CongurationonR1:
R1(config)#interfacegei-2/4
R1(config-if-gei-2/4)#noshutdown
R1(config-if-gei-2/4)#ipadd1.1.1.1255.255.255.0
R1(config-if-gei-2/4)#exit
R1(config)#interfacev6_tunnel2
R1(config-if-v6_tunnel2)#ipv6add82::/64eui-64
R1(config-if-v6_tunnel2)#ipv6enable
R1(config-if-v6_tunnel2)#exit
R1(config)#ipv6-tunnel-config
R1(config-ipv6-tunnel)#interfacev6_tunnel2
R1(config-ipv6-tunnel-if-v6_tunnel2)#tunnelmodeipv6ipisatap
R1(config-ipv6-tunnel-if-v6_tunnel2)#tunnelsourceipv41.1.1.1
R1(config-ipv6-tunnel-if-v6_tunnel2)#exit
R1(config-ipv6-tunnel)#exit
R1(config)#ipv6route81::/16v6_tunnel2
CongurationonR2:
R2(config)#interfacegei-3/4
R2(config-if-gei-3/4)#noshutdown
R2(config-if-gei-3/4)#ipadd1.1.1.2255.255.255.0
R2(config-if-gei-3/4)#exit
R2(config)#interfacev6_tunnel2
R2(config-if-v6_tunnel2)#ipv6add81::/64eui-64
R2(config-if-v6_tunnel2)#ipv6enable
R2(config-if-v6_tunnel2)#exit
R2(config)#ipv6-tunnel-config
R2(config-ipv6-tunnel)#interfacev6_tunnel2
R2(config-ipv6-tunnel-if-v6_tunnel2)#tunnelmodeipv6ipisatap
R2(config-ipv6-tunnel-if-v6_tunnel2)#tunnelsourceipv41.1.1.2
R2(config-ipv6-tunnel-if-v6_tunnel2)#exit
R2(config-ipv6-tunnel)#exit
