Chapter 4 WAN
Basic Home Station VDSL2 P8701T User’s Guide
88
IPoE
This screen displays when you select IP over Ethernet in the WAN Service Configuration
screen.
Bridge PPPoE
Frames Between
WAN and Local
Ports
Select this option to forward PPPoE packets from the WAN port to the LAN ports and
from the LAN ports to the WAN port.
In addition to the VDSL Router's built-in PPPoE client, you can select this to allow up to
ten hosts on the LAN to use PPPoE client software on their computers to connect to the
ISP via the VDSL Router. Each host can have a separate account and a public WAN IP
address.
This is an alternative to NAT for application where NAT is not appropriate.
Clear this if you do not need to allow hosts on the LAN to use PPPoE client software on
their computers to connect to the ISP.
This field is not available for a PPPoA connection.
Enable IGMP
Multicast Proxy
Select this check box to have the VDSL Router act as an IGMP proxy on this connection.
This allows the VDSL Router to get subscribing information and maintain a joined
member list for each multicast group. It can reduce multicast traffic significantly.
Enable MLD
Multicast Proxy
Select Enable to have the VDSL Router act as an MLD proxy on this connection. This
allows the VDSL Router to get subscription information and maintain a joined member
list for each multicast group. It can reduce multicast traffic significantly.
Back Click this button to return to the previous screen.
Next Click this button to continue.
Table 20 WAN Configuration: PPPoE or PPPoA
LABEL DESCRIPTION
