Specifications B-3
Cable Requirements
To remain compliant with the limits of a Class B digital
device, 3Com requires that you use quality interface
cables when connecting to these devices. Changes or
modifications not expressly approved by 3Com could
void the user’s authority to operate this equipment.
Suggested cable types are:
■ Thin Ethernet (50 ohm) for BNC connections:
3C530-xxx or equivalent
■ Thick Ethernet (50 ohm) for AUI connections:
3C120-xxx
■ Unshielded twisted-pair (100-ohm nominal):
– Level 3 LAN and high speed data cable. For
example, Anixter
®
CM-00424BAG-3 or
equivalent.
– Level 4 extended distance LAN cable. For
example, Anixter CM-00424BAG-4 or
equivalent.
