3Com EtherLink 3C509B User Manual

Performing Troubleshooting and Diagnostic Tests
7-2
This section contains information under the following
headings:
■ Starting the Diagnostic Program
■ Adapter Test Setup
■ Getting Help If a Test Fails
■ Changing the Test Setup
■ Group 2 and Group 3 Test Setup
■ Group 2 Test
■ Group 3 Test
Starting the Diagnostic Program
To use the EtherDisk diskette Configuration and
Diagnostic Program, use the following steps:
1. Boot your computer under DOS, version 3.1
or later.
2. Place the EtherDisk diskette in a floppy drive on
your computer and make that drive the active
drive. For example:
A: [Enter]
3. Type at the prompt:
INSTALL [Enter]
4. When an auto installation screen similar to that
shown in Figure 7-1 appears, press:
Y
5. Read the screen and press [Enter].
