3Com EtherLink 3C509B User Manual

Using the Configuration and Diagnostic Program
A-6
Dialog box
List
box
On-screen
command
help
Check
box

Radio
buttons

List
box
Command
buttons
Figure A-2. Sample Dialog Box
Exiting the Program
To exit a dialog box, press [Esc]. To exit the program,
choose Exit from the Quit menu or press [F3].
Using the Command Line
There are two ways to configure and test EtherLink III
adapters:
■ Automatically, from the menu program, by selecting the
options in the Configuration and Diagnostic submenu.
Typing 3C5X9CFG without a keyword or parameter
invokes the program in full windows mode, including
both mouse support and context-sensitive help. Press
[F1] for on-line help at any time.
