Pannoramic 250 1.15 User’s Guide 4 Software Description
• Give the number of the starting (First slide) and the final slide (Last slide) to be
scanned in the appropriate field. For example, if you want to scan slides to server
from 3-14, type: First slide: 3; Last slide: 14.
• There are two options at the bottom of the window.
1. The Generate slide name if no name was defined option can be activated when
you do not want to type in a unique name for each slide.
2. Upon activating the Read barcode if no name is defined on the list option, the
slide barcode will be read and set in the Barcode field.
• Use masks for automatic fills. Activate the Use mask option and the mask fields
become fillable. To save masks, click the Save Mask button. Click Set Mask to
modify masks.
For example, by creating a string for the slide name fields based on the characters
of the barcode, a unique name will be generated. The barcode '1234567890', and a
mask '1-3' result that the first three characters of the barcode will be displayed and
set as slide name (123). Case and Block fields can be set this way as well, if
necessary.
NOTE: When filling slide data fields, press TAB to move to the next cell.
Figure 75 – Profile selection
• Profiles can be added by selecting a list entry from the Profile drop-down list.
March 13, 2012 – Rev. 1 3DHISTECH Ltd.
111(135)
