162 Parameters
04.32 Warning word 2 ACS800-compatible warning (alarm) word 2.
The bit assignments of this word correspond to ALARM
WORD 2 in the ACS800. Parameter 04.120 Fault/Warning
word compatibility determines whether the bit assignments
are according to the ACS800 Standard or ACS800 System
control program.
Each may indicate several ACS880 warnings as listed below.
This parameter is read-only.
-
0000h…FFFFh ACS800-compatible warning (alarm) word 2. 1 = 1
04.40 Event word 1 User-defined event word. This word collects the status of the
events (warnings, faults or pure events) selected by
parameters 04.41…04.72.
For each event, an auxiliary code can optionally be specified
for filtering.
This parameter is read-only.
-
0000h…FFFFh User-defined event word. 1 = 1
No. Name/Value Description Def/FbEq16
Bit
ACS800 alarm name
ACS880 events indicated by this bit
(see Fault tracing, page 565)
(04.120 = ACS800
Standard ctrl
program)
(04.120 = ACS800
System ctrl
program)
0 Reserved MOTOR FAN A781
1 UNDERLOAD UNDERLOAD -
2 Reserved INV OVERLOAD -
3 Reserved CABLE TEMP A480
4 ENCODER ENCODER A<>B -
5 Reserved FAN OVERTEMP A984
6 Reserved Reserved -
7 POWFAIL FILE POWFAIL FILE -
8 ALM (OS_17) POWDOWN FILE -
9 MOTOR STALL MOTOR STALL A780
10 AI < MIN FUNC AI<MIN FUNC A8A0
11 Reserved COMM MODULE A6D1, A6D2, A7C1, A7C2, A7CA, A7CE
12 Reserved BATT FAILURE -
13 PANEL LOSS PANEL LOSS A7EE
14 Reserved DC UNDERVOLT A3A2
15 Reserved RESTARTED -
Bit Name Description
0 User bit 0 1 = Event selected by parameters 04.41 (and 04.42) is active
1 User bit 1 1 = Event selected by parameters 04.43 (and 04.44) is active
…… …
15 User bit 15 1 = Event selected by parameters 04.71 (and 04.72) is active
