ABB ACS880-104

Parameters 161
04.31 Warning word 1 ACS800-compatible warning (alarm) word 1.
The bit assignments of this word correspond to ALARM
WORD 1 in the ACS800. Parameter 04.120 Fault/Warning
word compatibility determines whether the assignments are
according to the ACS800 Standard or ACS800 System
control program.
Each may indicate several ACS880 warnings as listed below.
This parameter is read-only.
-
0000h…FFFFh ACS800-compatible warning (alarm) word 1. 1 = 1
No. Name/Value Description Def/FbEq16
Bit
ACS800 alarm name
ACS880 events indicated by this bit
(see Fault tracing, page 565)
(04.120 = ACS800
Standard ctrl
program)
(04.120 = ACS800
System ctrl
program)
0 START INHIBIT START INHIBI B5A0
1 Reserved EM STOP AFE1, AFE2
2 THERMISTOR MOTOR TEMP M A491
3 MOTOR TEMP MOTOR TEMP A492
4 ACS800 TEMP ACS800 TEMP A2BA, A4A1, A4A9, A4B0, A4B1, A4F6
5 ENCODER ERR ENCODER ERR A797, A7B0, A7B1, A7E1
6 T MEAS ALM T MEAS CIRC A490, A5EA, A782, A8A0
7 Reserved DIGITAL IO -
8 Reserved ANALOG IO -
9 Reserved EXT DIGITAL IO -
10 Reserved EXT ANALOG IO A6E5, A7AA, A7AB
11 Reserved CH2 COMM LOSS A7CB, AF80
12 COMM MODULE MPROT SWITCH A981
13 Reserved EM STOP DEC -
14 EARTH FAULT EARTH FAULT A2B3
15 Reserved SAFETY SWITC A983
