ABB ACS880-104

160 Parameters
04.22 Fault word 2 ACS800-compatible fault word 2.
The bit assignments of this word correspond to FAULT
WORD 2 in the ACS800. Parameter 04.120 Fault/Warning
word compatibility determines whether the bit assignments
are according to the ACS800 Standard or ACS800 System
control program.
Each bit can indicate several ACS880 events as listed below.
This parameter is read-only.
-
0000h…FFFFh ACS800-compatible fault word 2. 1 = 1
No. Name/Value Description Def/FbEq16
Bit
ACS800 fault name
ACS880 events indicated by this bit
(see Fault tracing, page 565)
(04.120 = ACS800
Standard ctrl
program)
(04.120 = ACS800
System ctrl
program)
0 SUPPLY PHASE SUPPLY PHASE 3130
1 NO MOT DATA NO MOTOR DATA -
2 DC UNDERVOLT DC UNDERVOLT 3220
3 Reserved CABLE TEMP 4000
4 RUN ENABLE RUN DISABLE AFEB
5 ENCODER ERR ENCODER ERR 7301, 7380, 7381, 73A0, 73A1
6 I/O COMM IO COMM ERR 7080, 7082
7 CTRL B TEMP CTRL B TEMP -
8 EXTERNAL FLT SELECTABLE 9082
9 OVER SWFREQ OVER SWFREQ -
10 AI < MIN FUNC AI<MIN FUNC 80A0
11 PPCC LINK PPCC LINK
5681, 5682, 5690, 5691, 5692, 5693, 5694,
5695
12 COMM MODULE COMM MODULE 6681, 7510, 7520, 7581
13 PANEL LOSS PANEL LOSS 7081
14 MOTOR STALL MOTOR STALL 7121
15 MOTOR PHASE MOTOR PHASE 3381
