Parameters 163
04.41 Event word 1 bit 0
code
Selects the hexadecimal code of an event (warning, fault or
pure event) whose status is shown as bit 0 of 04.40 Event
word 1. The event codes are listed in chapter Fault tracing
(page 565).
0000h
0000h…FFFFh Code of event. 1 = 1
04.42 Event word 1 bit 0
aux code
Specifies an auxiliary code for the event selected by the
previous parameter. The selected event is indicated by the
event word only if its auxiliary code matches the value of this
parameter.
With a value of 0000 0000h, the event word will indicate the
event regardless of the auxiliary code.
0000 0000h
0000 0000h …
FFFF FFFFh
Code of warning, fault or pure event. 1 = 1
04.43 Event word 1 bit 1
code
Selects the hexadecimal code of an event (warning, fault or
pure event) whose status is shown as bit 1 of 04.40 Event
word 1. The event codes are listed in chapter Fault tracing
(page 565).
0000h
0000h…FFFFh Code of event. 1 = 1
04.44 Event word 1 bit 1
aux code
Specifies an auxiliary code for the event selected by the
previous parameter. The selected event is indicated by the
event word only if its auxiliary code matches the value of this
parameter.
With a value of 0000 0000h, the event word will indicate the
event regardless of the auxiliary code.
0000 0000h
0000 0000h …
FFFF FFFFh
Code of warning, fault or pure event. 1 = 1
…… … …
04.71 Event word 1 bit 15
code
Selects the hexadecimal code of an event (warning, fault or
pure event) whose status is shown as bit 15 of 04.40 Event
word 1. The event codes are listed in chapter Fault tracing
(page 565).
0000h
0000h…FFFFh Code of event. 1 = 1
04.72 Event word 1 bit 15
aux code
Specifies an auxiliary code for the event selected by the
previous parameter. The selected event is indicated by the
event word only if its auxiliary code matches the value of this
parameter.
With a value of 0000 0000h, the event word will indicate the
event regardless of the auxiliary code.
0000 0000h
0000 0000h …
FFFF FFFFh
Code of warning, fault or pure event. 1 = 1
04.120 Fault/Warning word
compatibility
Selects whether the bit assignments of parameters
04.21…04.32 correspond to the ACS800 Standard control
program or the ACS800 System control program.
False
ACS800 Standard
ctrl program
The bit assignments of parameters 04.21…04.32 correspond
to the ACS800 Standard control program as follows:
04.21
Fault word 1: 03.05 FAULT WORD 1
04.22 Fault word 2: 03.06 FAULT WORD 2
04.31 Warning word 1: 03.08 ALARM WORD 1
04.32 Warning word 2: 03.09 ALARM WORD 2
0
No. Name/Value Description Def/FbEq16
