04.21 Fault word 1 ACS800-compatible fault word 1.
The bit assignments of this word correspond to FAULT
WORD 1 in the ACS800. Parameter 04.120 Fault/Warning
word compatibility determines whether the bit assignments
are according to the ACS800 Standard or ACS800 System
control program.
Each bit can indicate several ACS880 events as listed below.
This parameter is read-only.
-
0000h…FFFFh ACS800-compatible fault word 1. 1 = 1
No. Name/Value Description Def/FbEq16
Bit
ACS800 fault name
ACS880 events indicated by this bit
(see Fault tracing, page 565)
(04.120 = ACS800
Standard ctrl
program)
(04.120 = ACS800
System ctrl
program)
0 SHORT CIRC SHORT CIRC 2340
1 OVERCURRENT OVERCURRENT 2310
2 DC OVERVOLT DC OVERVOLT 3210
3 ACS800 TEMP ACS800 TEMP 2381, 4210, 4290, 42F1, 4310, 4380
4 EARTH FAULT EARTH FAULT 2330, 2392, 3181
5 THERMISTOR MOTOR TEMP M 4981
6 MOTOR TEMP MOTOR TEMP 4982
7 SYSTEM_FAULT SYSTEM_FAULT
6481, 6487, 64A1, 64A2, 64A3, 64B1, 64E1,
6881, 6882, 6883, 6885
8 UNDERLOAD UNDERLOAD -
9 OVERFREQ OVERFREQ 7310
10 Reserved MPROT SWITCH 9081
11 Reserved CH2 COMM LOSS 7582
12 Reserved SC (INU1) 2340 (XXYY YY01)
13 Reserved SC (INU2) 2340 (XXYY YY02)
14 Reserved SC (INU3) 2340 (XXYY YY03)
15 Reserved SC (INU4) 2340 (XXYY YY04)
