298 Parameters
30.19 Minimum torque 1 Defines a minimum torque limit for the drive (in percent of
nominal motor torque). See diagram at parameter 30.18
Minimum torque sel.
The limit is effective when
• the source selected by 30.18 Minimum torque sel is 0, or
• 30.18 is set to Minimum torque 1.
-300.0%
-1600.0 … 0.0% Minimum torque limit 1. See par.
46.03
30.20 Maximum torque 1 Defines a maximum torque limit for the drive (in percent of
nominal motor torque). See diagram at parameter 30.18
Minimum torque sel.
The limit is effective when
• the source selected by 30.25 Maximum torque sel is 0, or
• 30.25 is set to Maximum torque 1.
300.0%
0.0 … 1600.0% Maximum torque 1. See par.
46.03
30.21 Minimum torque 2
source
Defines the source of the minimum torque limit for the drive
(in percent of nominal motor torque) when
• the source selected by parameter 30.18 Minimum torque
sel is 1, or
• 30.18 is set to Minimum torque 2 source.
See diagram at 30.18 Minimum torque sel.
Note: Any positive values received from the selected source
are inverted.
Minimum
torque 2
Zero None. 0
AI1 scaled 12.12 AI1 scaled value (see page 197). 1
AI2 scaled 12.22 AI2 scaled value (see page 199). 2
PID 40.01 Process PID output actual (output of the process PID
controller).
5
Minimum torque 2 30.23 Minimum torque 2.6
Other Source selection (see Terms and abbreviations on page 148). -
30.22 Maximum torque 2
source
Defines the source of the maximum torque limit for the drive
(in percent of nominal motor torque) when
• the source selected by parameter 30.25 Maximum torque
sel is 1, or
• 30.25 is set to Maximum torque 2 source.
See diagram at 30.18 Minimum torque sel.
Note: Any negative values received from the selected source
are inverted.
Maximum
torque 2
Zero None. 0
AI1 scaled 12.12 AI1 scaled value (see page 197). 1
AI2 scaled 12.22 AI2 scaled value (see page 199). 2
PID 40.01 Process PID output actual (output of the process PID
controller).
5
Maximum torque 2 30.24 Maximum torque 2.6
Other Source selection (see Terms and abbreviations on page 148). -
No. Name/Value Description Def/FbEq16
