ABB ACS880-104

Parameters 317
33.20 On-time 2 actual Displays the actual present value of on-time timer 2.
The timer runs whenever the signal selected by parameter
33.23 On-time 2 source is on.
When the timer exceeds the limit set by 33.21 On-time 2 warn
limit, bit 1 of 33.01 Counter status is set to 1. The warning
specified by 33.24 On-time 2 warn message is also given if
enabled by 33.22 On-time 2 function.
The timer can be reset from the Drive composer PC tool, or
from the control panel by keeping Reset depressed for over 3
seconds.
-
0…4294967295 s Actual present value of on-time timer 2. -
33.21 On-time 2 warn limit Sets the warning limit for on-time timer 2. 0 s
0…4294967295 s Warning limit for on-time timer 2. -
33.22 On-time 2 function Configures on-time timer 2. 0000b
0000b…0011b On-time timer 2 configuration word. 1 = 1
33.23 On-time 2 source Selects the signal to be monitored by on-time timer 2. False
False Constant 0 (timer disabled). 0
True Constant 1. 1
RO1 Bit 0 of 10.21 RO status (page 188). 2
Other [bit] Source selection (see Terms and abbreviations on page 148). -
33.24 On-time 2 warn
message
Selects the optional warning message for on-time timer 2. On-time 2
exceeded
On-time 2
exceeded
A887 On-time 2. The message text can be edited on the
control panel by choosing Menu – Settings – Edit texts.
1
Clean device A88C Device clean.6
Maintain additional
cool fan
A890 Additional cooling.7
Maintain cabinet
fan
A88E Cabinet fan.8
Maintain DC
capacitors
A88D DC capacitor.9
Maintain motor
bearing
A880 Motor bearing.10
No. Name/Value Description Def/FbEq16
Bit Function
0 Counter mode
0 = Loop: When the limit is reached, the counter is reset. The counter status (bit 1 of
33.01) switches to 1 for one second. The warning (if enabled) stays active for at least 10
seconds.
1 = Saturate: When the limit is reached, the counter status (bit 1 of 33.01) switches to 1,
and remains so until 33.20 is reset. The warning (if enabled) also stays active until 33.20
is reset.
1 Warning enable
0 = Disable: No warning is given when the limit is reached
1 = Enable: A warning (see 33.24) is given when the limit is reached
2…15 Reserved
