ABB ACS880-104

320 Parameters
33.42 Edge counter 2
function
Configures signal edge counter 2. 0000b
0000b…1111b Edge counter 2 configuration word. 1 = 1
33.43 Edge counter 2
source
Selects the signal to be monitored by signal edge counter 2. False
False 0. 0
True 1. 1
RO1 Bit 0 of 10.21 RO status (page 188). 2
Other [bit] Source selection (see Terms and abbreviations on page 148). -
33.44 Edge counter 2
divider
Defines a divisor for signal edge counter 2. Determines how
many signal edges increment the counter by 1.
1
1…4294967295 Divisor for signal edge counter 2. -
33.45 Edge counter 2
warn message
Selects the optional warning message for signal edge counter
2.
Edge counter
2 exceeded
Edge counter 2
exceeded
A889 Edge counter 2. The message text can be edited on the
control panel by choosing Menu – Settings – Edit texts.
3
Counted main
contactor
A884 Main contactor.11
Counted output
relay
A881 Output relay.12
Counted motor
starts
A882 Motor starts.13
Counted power ups A883 Power ups.14
Counted DC
charges
A885 DC charge.15
No. Name/Value Description Def/FbEq16
Bit Function
0 Counter mode
0 = Loop: When the limit is reached, the counter is reset. The counter status (bit 3 of
33.01) remains 1 until the counter is again incremented. The warning (if enabled) stays
active for at least 10 seconds.
1 = Saturate: After the limit is reached, the counter status (bit 3 of 33.01) remains 1 until
33.40 is reset. The warning (if enabled) also stays active until 33.40 is reset.
1 Warning enable
0 = Disable: No warning is given when the limit is reached
1 = Enable: A warning (see 33.45) is given when the limit is reached
2 Count rising edges
0 = Disable: Rising edges are not counted
1 = Enable: Rising edges are counted
3 Count falling edges
0 = Disable: Falling edges are not counted
1 = Enable: Falling edges are counted
4…15 Reserved
