326 Parameters
PTC encoder
module 1
PTC sensor connected to encoder interface 1.
See also parameters 91.21 Module 1 temp sensor type and
91.22 Module 1 temp filter time.
9
PTC encoder
module 2
PTC sensor connected to encoder interface 2.
See also parameters 91.24 Module 2 temp sensor type and
91.25 Module 2 temp filter time.
10
Direct temperature The temperature is taken from the source selected by
parameter 35.14 Temperature 1 AI source. The value of the
source is assumed to be in the unit of temperature specified
by 96.16 Unit selection.
11
1 × Pt1000 analog
I/O
Pt1000 sensor connected to a standard analog input selected
by parameter 35.14 Temperature 1 AI source and an analog
output. The input and output can be on the drive control unit
or on an extension module.
The required settings are the same as with selection KTY84
analog I/O, except that the source selection parameter of the
analog output must be set to Force Pt1000 excitation.
13
2 × Pt1000 analog
I/O
As selection 1 × Pt1000 analog I/O, but with two sensors
connected in series. Using multiple sensors improves
measurement accuracy significantly.
14
3 × Pt1000 analog
I/O
As selection 1 × Pt1000 analog I/O, but with three sensors
connected in series. Using multiple sensors improves
measurement accuracy significantly.
15
35.12 Temperature 1 fault
limit
Defines the fault limit for temperature monitoring function 1.
When measured temperature 1 exceeds the limit, the drive
trips on fault 4981 External temperature 1.
The unit is selected by parameter 96.16 Unit selection.
Note: With a PTC sensor, the unit is ohms.
130 °C,
266 °F or
4500 ohm
-60 … 1000 °C,
-76 … 1832 °F or
0…5000 ohm
Fault limit for temperature monitoring function 1. 1 = 1 unit
35.13 Temperature 1
warning limit
Defines the warning limit for temperature monitoring function
1. When measured temperature 1 exceeds this limit, a
warning (A491
External temperature 1) is generated.
The unit is selected by parameter 96.16 Unit selection.
Note: With a PTC sensor, the unit is ohms.
110 °C,
230 °F or
4000 ohm
-60 … 1000 °C,
-76 … 1832 °F or
0…5000 ohm
Warning limit for temperature monitoring function 1. 1 = 1 unit
35.14 Temperature 1 AI
source
Specifies the analog input when the setting of 35.11
Temperature 1 source requires measurement through an
analog input.
Note: If the input is located on an I/O extension module, use
the selection Other to point to the AI actual value in group 14,
15 or 16, eg. 14.26 AI1 actual value.
Not selected
Not selected None. 0
AI1 actual value Analog input AI1 on the control unit. 1
AI2 actual value Analog input AI2 on the control unit. 2
Other Source selection (see Terms and abbreviations on page 148). -
