Parameters 333
35.100 DOL starter control
source
Parameters 35.100…35.106 configure a monitored start/stop
control logic for external equipment such as a contactor-
controlled motor cooling fan.
This parameter selects the signal that starts and stops the
fan.
0 = Stop
1 = Start
The output controlling the fan contactor is to be connected to
parameter 35.105, bit 1. On and off delays can be set for the
fan by 35.101 and 35.102 respectively. A feedback signal
from the fan can be connected to an input selected by 35.103;
the loss of the feedback will optionally trigger a warning or
fault (see 35.104 and 35.106).
Off; 06.16 b6
(95.20 b6)
Off 0 (function disabled). 0
On 1. 1
Running Bit 6 of 06.16 Drive status word 1 (see page 167). 2
Other [bit] Source selection (see Terms and abbreviations on page 148). -
35.101 DOL starter on
delay
Defines a start delay for the motor fan.
The delay timer starts when the control source selected by
parameter 35.100 switches on. After the delay, bit 1 of 35.105
switches on.
0 s
0…42949673 s Motor fan start delay. 1 = 1 s
35.102 DOL starter off
delay
Defines a stop delay for the motor fan.
The delay timer starts when the control source selected by
parameter 35.100 switches off. After the delay, bit 1 of 35.105
switches off.
20 min
0…715828 min Motor fan stop delay. 1 = 1 min
35.103 DOL starter
feedback source
Selects the input for motor fan feedback signal.
0 = Stopped
1 = Running
After the fan is started (bit 1 of 35.105 switches on), feedback
is expected within the time set by 35.104.
Not selected;
DI5
(95.20 b6)
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (
10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 148). -
