34 Quick start-up guide
Set motor nominal frequency. 99.08 Motor nominal frequency
Set motor nominal speed. 99.09 Motor nominal speed
Set motor nominal power. 99.10 Motor nominal power
Set motor cos
Φ.
Note: This value is not mandatory, but can
be entered to improve the control accuracy. If
not known, enter the value as zero (0).
99.11 Motor nominal cos Φ
Set sine filter data.
•Check 95.15 Special HW settings
• If ABB official filter is used, set bit1 ABB
sine filter = 1.
• If sine filter is supplied by other vendor,
set bit 3 Custom sine filter = 1.
• If no filter is used, make sure both bit1
and bit3 are set to 0.
• For filters other than ABB filter, it is also
important to provide filter data using
parameters 99.18 and 99.19.
95.15 Special HW settings
99.18 Sine filter inductance
99.19 Sine filter capacitance
Set used transformation ratio based on step-
up transformer tapping.
95.40 Transformation ratio
3 – Drive control interface settings
Set desired drive control interface.
Note: By default, the drive is configured to
start/stop from I/O interface. Other options
are available, including Fieldbus.
20.01 Ext1 commands
Set desired drive start trigger type.
Drive will react on edge or level status of
user start command based on this parameter
setting.
20.02 Ext1 start trigger type
If default control interface is used, select the
source for the drive control signal.
Note: By default, the drive starts/stops
according to the status of digital input DI1
(0 = Stop, 1 = Start).
20.03 Ext1 in1 source
Select desired motor stop mode: ramp or
coast.
21.03 Stop mode
