ABB ACS880-104

454 Parameters
90.22 Encoder 2 multiturn
revolutions
Displays the revolutions of (multiturn) encoder 2 within its
value range (see parameter 93.14 Revolution data width).
This parameter is read-only.
-
0…16777215 Encoder 2 revolutions. -
90.23 Encoder 2
revolution extension
Displays the revolution count extension for encoder 2.
With a single-turn encoder, the counter is incremented when
encoder position (parameter 90.21) wraps around in the
positive direction, and decremented in the negative direction.
With a multiturn encoder, the counter is incremented when
the revolutions count (parameter 90.22) exceeds the value
range in the positive direction, and decremented in the
negative direction.
This parameter is read-only.
-
-2147483648 …
2147483647
Encoder 2 revolution count extension. -
90.24 Encoder 2 position
raw
Displays the raw measurement data of encoder 2 position
(within one revolution) as a 24-bit unsigned integer received
from the encoder interface.
This parameter is read-only.
-
0…16777215 Raw encoder 2 position within one revolution. -
90.25 Encoder 2
revolutions raw
Displays the revolutions of (multiturn) encoder 2 within its
value range (see parameter 93.14 Revolution data width) as a
raw measurement.
This parameter is read-only.
-
0…16777215 Raw encoder 2 revolution count. -
90.26 Motor revolution
extension
Displays the motor revolution count extension.
The counter is incremented when the position selected by
90.41 Motor feedback selection wraps around in the positive
direction, and decremented in the negative direction.
This parameter is read-only.
-
-2147483648 …
2147483647
Motor revolution count extension. -
90.27 Load revolution
extension
Displays the load revolution count extension.
The counter is incremented when the position selected by
90.51 Load feedback selection wraps around in the positive
direction, and decremented in the negative direction.
This parameter is read-only.
-
-2147483648 …
2147483647
Load revolution count extension. -
No. Name/Value Description Def/FbEq16
