478 Parameters
95.21 HW options word 2 Specifies more hardware-related options that require
differentiated parameter defaults. See parameter 95.20 HW
options word 1.
WARNING! After switching any bits in this word,
recheck the values of the affected parameters.
-
0000b…0011b Hardware options configuration word 2. 1 = 1
95.30 Parallel type filter (Only visible with a BCU control unit)
Filters the list of drive/inverter types listed by parameter 95.31
Parallel connection rating id.
All types
All types All types listed. 0
-3 (380-415V) -3 (380…415 V) types listed. 1
-5 (380-500V) -5 (380…500 V) types listed. 2
-7 (525-690V) -7 (525…690 V) types listed. 3
95.31 Parallel connection
rating id
(Only visible with a BCU control unit)
Defines the drive/inverter type if it consists of parallel-
connected modules.
If the drive/inverter consists of a single module, leave the
value at Not selected.
Not selected
Not selected The drive/inverter does not consist of parallel-connected
modules, or type not selected.
0
[Drive/inverter type] Drive/inverter type consisting of parallel-connected modules. -
95.35 Adjustable supply
voltage
Enables manual setting for the supply voltage limits with
parameters 95.36 Supply voltage low and 95.37 Supply
voltage high.
Note: Enabling Adjustable supply voltage limits overrides
limits based on 95.01 Supply voltage or 95.02 Adaptive
voltage limits. This affects other soft limits in the drive
associated with the supply voltage.
WARNING! An incorrect setting may cause the motor
to rush uncontrollably, or the brake chopper or resistor
to overload.
Disable
Disable Adjustable supply voltage is disabled. 0
Enable Adjustable supply voltage is enabled. 1
No. Name/Value Description Def/FbEq16
Bit Name Information
0 Dual use 1 = Dual use active. For drives with option +N8200. (Allows higher
output frequencies and frequency reference limits.)
1 SynRM 1 = Synchronous reluctance motor used. Affects parameters 25.02,
25.03, 25.15, 99.03, 99.13.
2 Salient PM 1 = Salient-pole permanent magnet motor used. Affects parameters
25.02, 25.03, 25.15, 99.03, 99.13.
3…15 Reserved
