ABB ACS880-104

516 Additional parameter data
14.82 AO1 out at AO1 src min Real 0.000 … 22.000 mA 1000 = 1 mA
14.83 AO1 out at AO1 src max Real 0.000 … 22.000 mA 1000 = 1 mA
AO2 (14.01 Module 1 type = FAIO-01)
14.86 AO2 actual value Real 0.000 … 22.000 mA 1000 = 1 mA
14.87 AO2 source Analog
src
--1 = 1
14.88 AO2 force data Real 0.000 … 22.000 mA 1000 = 1 mA
14.89 AO2 filter time Real 0.000 … 30.000 s 1000 = 1 s
14.90 AO2 source min Real -32768.0 … 32767.0 - 10 = 1
14.91 AO2 source max Real -32768.0 … 32767.0 - 10 = 1
14.92 AO2 out at AO2 src min Real 0.000 … 22.000 mA 1000 = 1 mA
14.93 AO2 out at AO2 src max Real 0.000 … 22.000 mA 1000 = 1 mA
15 I/O extension module 2
15.01 Module 2 type List 0…4 - 1 = 1
15.02 Module 2 location Real 1…254 - 1 = 1
15.03 Module 2 status List 0…2 - 1 = 1
DIx (15.01 Module 2 type = FDIO-01)
15.05 DI status PB 00000000h…FFFFFFFFh - 1 = 1
15.06 DI delayed status PB 00000000h…FFFFFFFFh - 1 = 1
15.08 DI filter time Real 0.8 … 100.0 ms 10 = 1 ms
15.12 DI1 ON delay Real 0.00 … 3000.00 s 100 = 1 s
15.13 DI1 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
15.17 DI2 ON delay Real 0.00 … 3000.00 s 100 = 1 s
15.18 DI2 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
15.22 DI3 ON delay Real 0.00 … 3000.00 s 100 = 1 s
15.23 DI3 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
Common parameters for DIOx (15.01 Module 2 type = FIO-01 or FIO-11)
15.05 DIO status PB 00000000h…FFFFFFFFh - 1 = 1
15.06 DIO delayed status PB 00000000h…FFFFFFFFh - 1 = 1
DIO1/DIO2 (15.01 Module 2 type = FIO-01 or FIO-11)
15.08 DIO filter time Real 0.8 … 100.0 ms 10 = 1 ms
15.09 DIO1 function List 0…1 - 1 = 1
15.11 DIO1 output source Binary
src
--1 = 1
15.12 DIO1 ON delay Real 0.00 … 3000.00 s 100 = 1 s
15.13 DIO1 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
15.14 DIO2 function List 0…1 - 1 = 1
15.16 DIO2 output source Binary
src
--1 = 1
15.17 DIO2 ON delay Real 0.00 … 3000.00 s 100 = 1 s
15.18 DIO2 OFF delay Real 0.00 … 3000.00 s 100 = 1 s
No. Name Type Range Unit FbEq32
