PREPARING FOR INSTALLATION
28 FOX615Installation
Figure 12: Mechanical dimensions FAMO1-F fan unit
2.4.1.8 Heat deflection shield R7AI 2 HU
The Figure 13 shows the mechanical dimensions of the 19-inch heat deflec-
tion shield R7AI with a height of 2 HU.
Figure 13: Mechanical dimensions heat deflection shield R7AI 2 HU
2.4.1.9 Heat deflection shield R7AI 1 HU
The Figure 14 shows the mechanical dimensions of the 19-inch heat deflec-
tion shield R7AI with a height of 1 HU.
F3: Alarm inputs
1-4
F4: Alarm inputs
5-8
F5: Alarm inputs
9-12
F2: Alarm output
1-2
50
alarm 48VDC 19" 1U
37970003
R2A
2111743473
2011W44
20.0 mm
17.2 mm
444.5 mm
31.8 mm
465.2 mm
482.6 mm
19.8 mm
43.6 mm
16.9 mm
2.0 mm
2.0 mm
226.0 mm
444.8 mm
5.8 mm
76.2 mm
465.2 mm
482.6 mm
228.0 mm
87.8 mm
