INSTALLATION PROCEDURES
FOX615Installation 39
3.2 ETSI adapters (option)
The FOX615 equipment directly fits to 19-inch racks. To install the FOX615
in ETSI racks you must first install the appropriate ETSI adapters.
ETSI adapters are available as follows:
Figure 20: FOX615 installation with 11 HU ETSI adapters
Table 5: ETSI adapters
ETSI adapters Equipment
Height units Fixing holes N
a
Cable Tray Subrack FAMO1
FAMO1-F
(optional)
Heat Deflection
(optional)
11 HU 5 X X X X
9 HU 4 X X X
2 HU 2 X
9 HU + 2 HU 4 + 2 X X X X
a. N corresponds to the number of holes that each ETSI adapter provides to fix the
adapter to the nuts in the ETSI rack.
F
O
X
6
1
5
s
u
b
r
a
c
k
F
A
M
O
1
o
r
F
A
M
O
1
-
F
H
e
a
t
d
e
f
l
e
c
t
i
o
n
s
h
i
e
l
d
R
7
A
I
C
a
b
l
e
tr
a
y
