ABB FOX615 - Torques

PREPARING FOR INSTALLATION
34 FOX615Installation
2.4.3 Torques
Torques as follows apply for the installation of 19-inch/ETSI equipment (sub-
racks, cable tray, FAMO1, FAMO1-F, heat deflection shields, adapters) and
the screws of the unit front covers in the FOX615 subrack.
Table 4: Torques
Screw Use/application Torque [Nm]
Recommended Maximum
M2.5 Unit front covers 0.45 0.56
M2.5 (4.8) DUPF1 - 0.34
M6 (4.8) Earthing / bonding
terminal
- 4.7
M6 (4.8) 19-inch / ETSI
equipment (sub-
racks) and adapters
- 4.7
