INSTALLATION PROCEDURES
FOX615Installation 37
Figure 19: Subrack packing assembly of the FOX615
1 19-inch subrack including front cover (not shown)
2 Power supply cable for subrack
3 19-inch cable tray
1
2
3
430 mm
540 mm
3
8
0
m
m
