PREPARING FOR INSTALLATION
30 FOX615Installation
Figure 15: ETSI installation standard for the FOX615
1 19-inch cable tray mounted on ETSI adapters
2 19-inch subrack mounted on ETSI adapters
3 19-inch FAMO1 or FAMO1-F mounted on ETSI adapters (option)
4 19-inch heat deflection shield R7AI mounted on ETSI adapters (option)
5 ETSI adapters 11 HU
Installations without the heat deflection shield R7AI use 9 HU ETSI
adapters.
88.9 mm
2HU
266.7 mm
6HU
1HU
2HU
88.9 mm
44.45 mm
1
2
3
4
500 mm
55
465.1 mm
515 mm
600 mm
427.5 mm
20.3 mm
F3: Alarm inputs
1-4
F4: Alarm inputs
5-8
F5: Alarm inputs
9-12
F2: Alarm output
1-2
50
moving fans
refer to handbook
fan 48VDC 19" 1U
37970003
R2A
2111743473
2011W44
