INSTALLATION PROCEDURES
FOX615Installation 63
Please note:
Figure 34 shows the front connection of the external power supply circuits
(PSC 1, PSC 2).
It is also possible to implement the WAGO connector blocks (S
1
, S
2
) for rear
connection of the power supply circuit. In this case the subrack power cables
leave from the front and the plus/minus polarities on the WAGO connector
block appear reversed compared to the presentation in Figure 34.
Power supply connection to
DUPF1
Proceed as follows:
1. Turn the TYCO connector of the left and right power cables in such a
way that the blue cables are on top (connector key to the left).
2. Locate the TYCO connector of the left power cable in front of the left “D
2
”
power interface of the DUPF1.
3. Locate the TYCO connector of the right power cable in front of the right
“D
1
” power interface of the DUPF1.
4. Plug the TYCO connectors firmly to the fast-on contacts on the DUPF1
interfaces “D
1
” and “D
2
”.
5. Align the left and right power cables as appropriate inside the cable tray.
6. Check the left and right power connections for firm fit.
End of instruction
WARNING
Hazardous electric currents. Risk of flashover and electric shock!
The DUPF1 has no fuses for the external power supplies.
→ The power supply circuits 1 and 2 must be fused for the operation with
DUPF1.
