DescriptionData typeR/W
1)
Par. no.
Selected PPO typeUnsigned16R929
PPO typeValue
PPO11
PPO22
PPO33
PPO44
PPO55
PPO66
PPO77
Note:
This parameter is not available if Standard telegram ST1 or
ST2 is selected.
Selection switch for communication profile.Unsigned16R/W930
ModeValue
PROFIdrive1
ABB Drives8001h
Transparent 168002h
Transparent 328003h
PROFIdrive positioning mode8004h
Selection switch for Control word, bit 11.Unsigned16R/W933
Module Control with bitValue
None0
Vendor-specific 1 to 5
2)
1 to 5
Selection switch for Control word, bit 12. (See parameter 933
for coding.)
Unsigned16R/W934
Selection switch for Control word, bit 13. (See parameter 933
for coding.)
Unsigned16R/W935
Selection switch for Control word, bit 14. (See parameter 933
for coding.)
Unsigned16R/W936
Selection switch for Control word, bit 15. (See parameter 933
for coding.)
Unsigned16R/W937
Selection switch for Status word, bit 11.Unsigned16R/W939
Module Status word bitValue
None0
Vendor-specific 1 to 4
2)
1 to 4
Selection switch for Status word, bit 12. (See parameter 939
for coding.)
Unsigned16R/W940
Selection switch for Status word, bit 13. (See parameter 939
for coding.)
Unsigned16R/W941
Appendix A – PROFIdrive parameters and I&M records of PROFINET IO 203
